Admin asset types

An Asset Type is a definition made up of a set of attributes. You can create your own Asset types. Assets of those types can then be created.

Parent-child tree

Asset types can have parent-child relationships to each other, thus forming hierarchical trees. Assets of Parent types will contain assets of Child types.

View, edit, clone and delete asset types

Click Asset Types in the left menu:

Search or filter the asset types you want to view.
Here is an asset type example:

You can edit, clone, or delete the asset type by selecting the respective icon on the top right of the page:

Add asset type

Click Asset Types on the left menu:
Click the plus button on the top right of the page.
This is what the Details section (first one that appears) looks like:
Toggle “Asset” or “Area” to select the entity type. If you choose “Area,” you will be able to define a geofence for assets of this type.
This is what the Attributes section looks like:
This is what the Controls section looks like:
This is what the Categorize section looks like:
When done filling out the information, click the create button at the bottom of the page.

Here is a creating asset types video.

Required values

Value	Definition
ID	The asset type’s unique ID
Name	The asset type’s name
Groups	The groups the asset type belongs to

Optional values

Value	Definition
Icon	Please select one from our icon library or upload an image
Description	The asset type’s description
Children	Other related asset types can be added as children of this parent asset type
Default History View	There are different view settings for the asset type’s data history
Device Type	The device used for the assets with this type (e.g., NimbeLink)
Propagate location to root?	If checked, the location updates the asset and roots
Show location on root?	If checked, assets of this type display on maps
Store updates on root?	If checked, the updates for an asset of this type only update for the root asset and its history

Attributes

Note: The Name value is required. Others are optional.

Value	Definition
Name	The attribute’s name
Label	The attribute’s displayed label
Data Type	The attribute appearance’s data type
Edit Widget	Sets up the widget type to edit an area’s attributes
View Widget	How Edit Widget appears
Keep History?	When checked, the history of changes is recorded as historical data under Areas in the Monitor tab
Hide Attribute?	When checked, it hides the attribute
Read Only Attribute?	When checked, the attribute cannot be edited by a user

Image Attributes

Attributes of type Image can be added to Asset Types. The choices for Edit Widget are Text input or Text area. Then an image can be added to an asset by converting the image to a formatted base64 string and pasting the string into the Text input/area Edit widget.

The string should be formatted as follows:
data:<MIME_type>:base64,<image-as-base64-encoded-string>

For example…

Commonly used examples of MIME_type are:

image/jpeg
image/png
image/bmp

Others can be used as well.

There are free online tools available that will convert images into properly formatted base64 strings.

Calculated Attributes

Calculated attributes are a powerful way to create new values based on multiple attributes, utilizing a powerful formula builder. These formulas can contain a number of operators, functions, and variables. When adding an attribute, after setting a name for the attribute, click the “Calculated Attribute?” checkbox at the bottom to open the formula builder.

Example formulas

Calculate Fahrenheit from a Celsius attribute -
1. (celsius * (9/5)) + 32
Total energy usage for a building (note: there are multiple ways to solve this)
1. reduce(childLightBulbs, childLightBulb.energyUsage)
2. sum(map(childLightBulbs, childLightBulb.energyUsage))
3. reduce with filter reduce(filter(childLightBulds, childLightBulb.isReporting == true), childLightBulb.energyUsage)
4. map with filter sum(map(filter(childLightBulbs, childLightBulb.isReporting == true), childLightBulb.energyUsage))
Condition where temperature is over set point
1. currentTemp > (setPoint + 2)

Types of operators

Arithmetic

Type	Definition
Addition (+)	To add two numbers or variables
Subtraction (-)	To subtract one number or variable from another
Multiplication (*)	To multiply two numbers or variables
Division (/)	To divide one number or variable by another
Modulo (%)	To find the remainder of the division of one number by another

Comparison

Type	Definition
Equal to (==)	To check if two values are equal
Not equal to (!=)	To check if two values are not equal
Greater than (>)	To check if one value is greater than another
Less than (<)	To check if one value is less than another
Greater than or equal to (>=)	To check if one value is greater than or equal to another
Less than or equal to (<=)	To check if one value is less than or equal to another
AND (&&)	To check if both conditions are true
OR (\|\|)	To check if at least one condition is true
NOT (!)	To invert the truth value of a condition

Types of Functions

Aggregate

Type	Definition
SUM(array[])	To find the sum of a list of numbers
AVG(array[])	To find the average of a list of numbers
MIN(array[])	To find the minimum value in a list of numbers
MAX(array[])	To find the maximum value in a list of numbers

String

Type	Definition
concat(string1, string2, …string)	To concatenate multiple strings into one
replace(original, regex, replacement)	To replace parts of a string
split(string, delimiter)	To split a string into an array based on a delimiter
join(array, delimiter)	To join an array of strings into a single string with a delimiter
match(string, regex)	To match a string against a regular expression

Array

Type	Definition
map(array, mapOperation)	To map elements of an array to another array
reduce(array, reduceOperation)	To reduce an array to another value
filter(array, filterOperation)	To filter elements from an array
length(array)	To get the length of an array
contains(array, value)	To check if an array contains a specific value
indexof(array, value)	To get the index of a value in an array

Conditional

Type	Definition
if(condition, true_value, false_value)	To return a value based on a condition
case(expression, value1, result1, value2, result, …, else_result)	To return a value based on multiple conditions

Statistical

Type	Defintion
median(array[])	To find the median of a list of numbers
stddev(array[])	to calculate the standard deviation of a list of numbers
variance(array[])	To calculate the variance of a list of numbers
percentile(array[])	To find the percentile of a list of numbers

Controls

Value	Definition
ID	The control’s ID
Widget Type	The attribute’s displayed label
Control Type	Fire and Forget is the default
Label	The control’s label
Variant	The label’s display
